31-34Kva Generator Set Disesl HYW-40 M5

Specifications:

31-34Kva Generator Set Disesl HYW-40 M5

ENGINE

Engine Specifications 1.500 r.p.m.

Rated Engine Output: 37,7kW prp ; 41,8kW standby

Manufacturer: YANMAR

Model: 4TNV98TZGGEHR

Engine Type: 4-stroke diesel

Injection Type: Direct

Aspiration Type: Turbocharged

Number of cylinders and arrangement: 4-L

Bore and Stroke: 98 x 110 mm

Displacement: 3,319 L

Cooling System: Coolant

Lube Oil Specifications: API CF,CF-4,CI-4

Compression Ratio: 18.1

Fuel Consumption ESP: 10,11 l/h

Fuel Consumption 100% PRP: 9,16 l/h

Fuel Consumption 75 % PRP: 6,94 l/h

Fuel Consumption 50 % PRP: 4,89 l/h

Lube oil consumption with full load: 0,27

Total oil capacity: 11,2 L

Total coolant capacity: 9 L

Governor Type Electrical

Air Filter Type Dry

Inner diameter exhaust pipe: 45 mm

Diesel engine

4-stroke cycle

Water-cooled

12V electrical system

Water separator filter (visible level)

Dry air filter

Radiator with pusher fan

Electronic governor

Hot parts protection

Moving parts protection
