| Products Generator Set Diesel Generator set 35-38KVA HYW-35 T5 S5 Stage V Generator set
  • 35-38KVA HYW-35 T5 S5 Stage V Generator set
  • 35-38KVA HYW-35 T5 S5 Stage V Generator set
  • 35-38KVA HYW-35 T5 S5 Stage V Generator set
  • 35-38KVA HYW-35 T5 S5 Stage V Generator set
  • 35-38KVA HYW-35 T5 S5 Stage V Generator set

    • 35-38KVA HYW-35 T5 S5 Stage V Generator Set

    • 435
    Product Review | Top Rated

      Additional Information

    • Color: Default Color
    • Size: Default Size
    • Origin: China
    • Usage: Default Usage
    • Type: Default Type
    • Efficiency: 99.9% Type
    Inquire Now

    Description:

    • Engine Specifications 1.500 r.p.m.
    • Rated Engine Output: 31,6kW prp ; 35,2kW standby
    • Manufacturer: YANMAR
    • Model: 4TNV98CIHR
    • Engine Type: 4-stroke diesel
    • Injection Type: Direct
    • Aspiration Type: Natural
    • Number of cylinders and arrangement: 4-L
    • Bore and Stroke: 98 x 110 mm
    • Displacement: 3,319 L
    • Cooling System: Coolant
    • Lube Oil Specifications: API CJ-4, ACEA E6, JASO DH-2
    • Compression Ratio: 18,3
    • Fuel Consumption ESP: 9,68 l/h
    • Fuel Consumption 100% PRP: 8,20 l/h
    • Fuel Consumption 75 % PRP: 6,04 l/h
    • Fuel Consumption 50 % PRP: 3,99 l/h
    • Fuel Consumption 25 % PRP: 2,23 l/h
    • Total oil capacity: 10,5 L
    • Total coolant capacity: 9 L
    • Governor Type Electrical
    • Air Filter Type Dry
    • Diesel engine
    • 4-stroke cycle
    • Water-cooled
    • 12V electrical system
    • Water separator filter (visible level)
    • Dry air filter
    • Radiator with pusher fan
    • Electronic governor
    • Hot parts protection
    • Moving parts protection

    • This Stage V–compliant generator set delivers reliable power, fuel efficiency, and proven Yanmar performance for demanding operations. Explore our high-capacity diesel generator supply solutions to find scalable options designed for industrial, commercial, and large project requirements worldwide.
