Engine Specifications 1.500 r.p.m.
Rated Engine Output: 29,99kW prp ; 34,46kW standby
Manufacturer: FORD
Model: LSG635
Engine Type: 4-stroke Miller Cycle
Injection Type: Carburization
Aspiration Type: Natural
Number of cylinders and arrangement: 6-V
Bore and Stroke: 92,5 x 86,7 mm
Displacement: 3,5 L
Cooling System: Liquid (water + 50% glycol)
Lube Oil Specifications: API ≥SH, SAE 10W-30
Compression Ratio: 11,8
Fuel Consumption 100% PRP: 353.81 cfh
Total oil capacity including tubes, filters 5,68 L
Governor Type Electrical
Air Filter Type Dry
Natural Gas engine
4-stroke cycle
Water-cooled
12V electrical system
Dry air filter
Radiator with pusher fan
HTW sender
LOP sender
Electronic governor
Hot parts protection
Moving parts protection
